Diagnostic Soft OLED is a separate, non-NCC range using high-quality flexible OLED panels with post-repair diagnostic support. After installation, complete the device's built-in Repair Parts process. Once completed, the screen is designed to register as Used in Parts and Service History rather than Unknown.
True Tone support: Yes; IC transplant support: Yes.
Tested before dispatch and covered by a two-year Australian warranty against manufacturing faults.
Diagnostic requirement: Complete the device's Repair Parts process after installation.
Diagnostic compatibility: The diagnostic process may not complete if the battery or rear camera has been replaced with non-original or non-diagnosable components.
Sensor flex requirement: For iPhone 15 and iPhone 16 series repairs, the sensor flex assembly must remain matched to the original device for the Repair Parts diagnostic process.
Technical specifications
- Screen Type: Diagnostic Soft OLED
- True Tone Support: Yes
- Supports IC Transplant: Yes
- Sensor Flex Requirement: Must remain matched to the original device for diagnostics
- Compatible Models: A2846, A3089, A3092, A3090
- Contains: Screen Assembly & Display Adhesive
Diagnostic note: Keep the original matched sensor flex for the Repair Parts process on supported models.
Testing: Before applying adhesive, connect the screen and test image, touch and brightness.
Transfer required: Transfer the original front sensor assembly to the replacement screen before reassembly.
Warranty label: Keep any QR or identification sticker supplied on the screen intact. Removing it can void warranty coverage.
Screen replacement work covers more than cracked outer glass. A failed panel may show lines, black areas, flicker, an incomplete image or touch faults. The available screen technologies and quality grades vary by model, so compare the product title and specifications instead of assuming every screen for a phone is equivalent.
Explore iphone replacement screens to compare this part type, and browse iPhone 15 Parts for other components used with the same device.
Check the phone for signs of impact, moisture or bent housing before confirming a screen fault. A blank image may also follow connector damage or a board issue. If the image is present but touch input is unreliable, inspect the flex connectors and rule out pressure or frame damage before fitting another screen. Test brightness, colours and touch over the full panel before closing the device.
Where a screen needs resealing, match the replacement with suitable iphone screen adhesives and seals.
Match the exact iPhone model and screen grade. Some repairs require transfer of device matched sensors or other components, and diagnostic screen options have specific conditions. Review the product notes before starting work. Check the frame for debris and use the correct adhesive when resealing. Do not assume that a different screen technology supports every function of the factory fitted panel.
For careful disassembly and fitting, choose suitable repair tools and protect nearby components.
Pacific Repair Parts supplies model-specific replacement parts and accessories to approved trade customers across Australia. Where functional testing applies, electronic parts are checked before dispatch. Check the exact model, selected quality grade and any included components before ordering. Our two-year Australian warranty covers manufacturing faults, subject to the published terms and exclusions.
Orders placed before 2 PM AEST on business days are dispatched from Brisbane on the same day when stock is available, excluding public holidays. Australia Post tracking is provided after dispatch. Trade customers can check their account pricing and current availability after signing in.
